SoundOutput Class Reference

Manages audio output format, buffering and the underlying sink. More...

#include <SoundOutput.h>

Inheritance diagram for SoundOutput:

Collaboration diagram for SoundOutput:

Public Slots
void	setFormat (QAudioDevice const &device, unsigned channels, unsigned msBuffered=0u)
	Configure format based on device and channel count.
void	setDeviceFormat (QAudioDevice const &device, QAudioFormat const &format, unsigned msBuffered=0u)
	Set device and explicit format to use for playback.
void	restart (QIODevice *source)
	Restart output streaming from the given QIODevice source.
void	suspend ()
	Temporarily suspend output streaming.
void	resume ()
	Resume output after a suspend.
void	reset ()
	Reset internal state and stop any active stream.
void	stop ()
	Stop playback immediately.
void	setAttenuation (qreal value)
	Set attenuation (volume multiplier) for playback.
void	resetAttenuation ()
	Reset attenuation to default (unity) value.

Signals
void	error (QString message) const
	Emitted when an error occurs related to audio output.
void	status (QString message) const
	Emitted to report informational status updates.

Public Member Functions
	SoundOutput ()=default
	Default-construct a SoundOutput helper.
qreal	attenuation () const
	Current attenuation (volume multiplier).
QAudioFormat	format () const
	Active audio format used by the output.

Detailed Description

Manages audio output format, buffering and the underlying sink.

Responsible for configuring a QAudioSink, managing buffering latency, and applying attenuation for playback. Typical usage is to call setFormat() or setDeviceFormat() and then restart() with a prepared QIODevice for streaming audio.

Member Function Documentation

attenuation()

qreal SoundOutput::attenuation

(

)

const

Current attenuation (volume multiplier).

Gets the current attenuation in decibels.

Returns

Attenuation factor where 1.0 is unity gain.

The attenuation value.

error

void SoundOutput::error ( QString message ) const

signal

Emitted when an error occurs related to audio output.

Parameters

message

Human-readable error description.

Here is the caller graph for this function:

format()

QAudioFormat SoundOutput::format

(

)

const

Active audio format used by the output.

Gets the current audio format.

Returns

The QAudioFormat currently configured for playback.

The QAudioFormat object.

Here is the caller graph for this function:

reset

void SoundOutput::reset ( )

slot

Reset internal state and stop any active stream.

Resets the audio output.

resetAttenuation

void SoundOutput::resetAttenuation ( )

slot

Reset attenuation to default (unity) value.

Resets the attenuation to zero.

restart

void SoundOutput::restart ( QIODevice * source )

slot

Restart output streaming from the given QIODevice source.

Restarts audio output with the specified source.

Parameters

source	The device providing audio samples for playback.
source	The QIODevice to read audio data from.

Here is the call graph for this function:

resume

void SoundOutput::resume ( )

slot

Resume output after a suspend.

Resumes audio output.

setAttenuation

void SoundOutput::setAttenuation ( qreal a )

slot

Set attenuation (volume multiplier) for playback.

Sets the attenuation in decibels.

Parameters

value	Attenuation factor where 1.0 is no attenuation.
a	The attenuation value.

Here is the caller graph for this function:

setDeviceFormat

void SoundOutput::setDeviceFormat ( QAudioDevice const & device, QAudioFormat const & format, unsigned msBuffered = 0u )

slot

Set device and explicit format to use for playback.

Sets the audio device and format.

Parameters

device	Output device to use.
format	Exact audio format to use for the sink.
msBuffered	Milliseconds of buffering to set up (0 = default).
device	The QAudioDevice to use.
format	The QAudioFormat to set.
msBuffered	The buffer size in milliseconds.

Here is the call graph for this function:

Here is the caller graph for this function:

setFormat

void SoundOutput::setFormat ( QAudioDevice const & device, unsigned channels, unsigned msBuffered = 0u )

slot

Configure format based on device and channel count.

Sets the audio format based on the device and channel count.

Parameters

device	Output device to use.
channels	Number of channels (1 or 2).
msBuffered	Milliseconds of buffering to set up (0 = default).
device	The QAudioDevice to use.
channels	The number of audio channels (1 for mono, 2 for stereo).
msBuffered	The buffer size in milliseconds.

Here is the call graph for this function:

Here is the caller graph for this function:

status

void SoundOutput::status ( QString message ) const

signal

Emitted to report informational status updates.

Parameters

message

Status text.

stop

void SoundOutput::stop ( )

slot

Stop playback immediately.

Stops audio output.

suspend

void SoundOutput::suspend ( )

slot

Temporarily suspend output streaming.

Suspends audio output.

---

The documentation for this class was generated from the following files:

• JS8_Audio/SoundOutput.h
• JS8_Audio/SoundOutput.cpp
